Frame : OCLV Mountain Carbon, IsoBow, tapered head tube, internal routing, balanced post mount brake, Boost148
Fork : RockShox Judy GOLD, Solo Air spring, TurnKey lockout, tapered steerer, 42mm offset, Boost110, 15mm Maxle Stealth, 120mm travel
Max compatible fork travel : 120mm

Hub front : Shimano TC500 alloy, centerlock, 110x15mm thru axle
Hub rear : Shimano TC500 alloy, centerlock, 148x12mm thru axle
Skewer rear : Bontrager Switch thru axle, removable lever
Rim : Bontrager Kovee, double-wall, Tubeless Ready, 28-hole, 23mm width, Presta valve
*Tire
: Size: S, M, ML, L, XL
Bontrager Sainte-Anne Pro XR, Tubeless Ready, dual compound, aramid bead, 60 tpi, 29×2.40”
Size: S, M, ML, L, XL
Bontrager Sainte-Anne Pro XR, Tubeless Ready, dual compound, aramid bead, 60 tpi, 29×2.20”
Tire part : Bontrager TLR sealant, 6oz
Rim strip : Bontrager TLR
Max tire size : Frame: 29×2.40″, Fork: See manufacturer

Shifter : Shimano Deore M6100, 12 speed
Rear derailleur : Shimano Deore M6100, long cage
Crank
: Size: S, M, ML
Shimano MT512, 32T, 55mm chainline, 170mm
Size: L, XL
Shimano MT512, 32T, 55mm chainline, 175mm
Bottom bracket : Shimano MT500, 92mm, PressFit
Cassette : Shimano Deore M6100, 10-51, 12 speed
Chain : Shimano Deore M6100, 12 speed
Max chainring size : 1x: 38T

Saddle : Verse Short, chromoly rails, 145mm width
Seatpost
: Size: S
Bontrager Line Dropper, 100mm travel, MaxFlow, internal routing, 31.6mm, 310mm length
Size: M, ML, L
Bontrager Line Dropper, 150mm travel, MaxFlow, internal routing, 31.6mm, 410mm length
Size: XL
Bontrager Line Dropper, 170mm travel, MaxFlow, internal routing, 31.6mm, 450mm length
Handlebar
: Size: S
Bontrager Comp, alloy, 31.8mm, 5mm rise, 720mm width
Size: M, ML, L, XL
Bontrager Rhythm Comp, alloy, 31.8mm, 15mm rise, 750mm width
Grips : Bontrager XR Trail Comp, nylon lock-on
Stem
: Size: S
Bontrager Comp, 31.8mm, Blendr compatible, 7 degree, 50mm length
Size: M, ML
Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 60mm length
Size: L
Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 70mm length
Size: XL
Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 80mm length
Headset : FSA IS-2, 1-1/8” top, 1.5” bottom
Brake : Shimano MT200 hydraulic disc
Brake rotor
: Size: S, M, ML, L, XL
Shimano RT10, centerlock, 160mm
Size: L, XL
Shimano RT10, centerlock, 180mm
Brake Set Shimano MT200 hydraulic disc
Rotor size : Max brake rotor sizes – Frame: 180mm, Fork: see fork manufacturer

Tool : Bontrager Switch thru axle, removable lever

Weight : M – 12.13 kg / 26.75 lbs (with TLR sealant, no tubes)
Weight limit : This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg).
